Sylfan Frusto
Baker-Smith Sylfan 'Frusto',model F cone speaker
Jodra The Enchanter
Jodra 'The Enchanter', model G cone speaker

Baker-Smith Co., Inc. and Jodra Mfg. Co. both produced the same line-up of speakers, so I am grouping the Enchanter and Frusto speakers here together. One company probably superseded the other.

Click the photo to see more!
Best No. 1
Best horn speaker
Small metal horn speaker with a 'Best' driver. Sound is directed into the bell and reflects back out.
Best No. 2
Best horn speaker
Small ceramic horn speaker with a 'Best' driver. Sound is directed straight up into the bell and reflects back out.
Borkman Chinese Coneflex
Borkman No. 18
'The Chinese Cone-Flex'
horn speaker
Manufactured by Borkman Radio Corporation of Salt Lake City in 1926. The driver is underneath and points straight up into the cavity of the speaker for amplification.

Click the photo to see more!
Bristol Audiophone
Bristol Audiophone Senior horn speaker

Largest of the three horn speakers manufactured by Bristol, an impedance matching transformer is hidden in the metal base. Input resistance to this transformer is only 240 ohms. The driver has an armature driven diaphragm for better low frequency response than was typical for horn speakers. A knurled coupler can be unscrewed to remove the metal bell from the driver. The bell/driver assembly swivels on the base. The speaker measures 21-1/2 inches tall, bell diameter is 15-3/8 inches, and the color was advertised as 'dull gold bronze'.
Bristol Baby Grand Audiophone
Bristol Baby Grand Audiophone horn speaker

Smallest of the three horn speakers manufactured by Bristol, the metal base houses a conventional, iron diaphragm-type driver with an input impedance of 1000 ohms. It has a black composition horn with a 10-3/8 inch opening.
Burndept Peter Pan
Burndept 'Peter Pan' horn speaker
A rare little 1920s horn speaker measuring just 10 inches tall and with a 6-1/4-inch aluminum bell. It has a 2000 ohm adjustable driver and has 'Burndept Peter Pan' lightly printed on the lower front edge of the bell.
Burns: see American Electric Company
